Available

90kW Black Inverter

Name: 90kW Black Inverter
Brand: TOFEL
SKU: TF1023/90KW/BK
Price: 8768.18 SAR
Availability: InStock

SAR 8,768.18

العدد المتبقي : 4

Remaining 4 only

Earn loyalty points with this purchase

Rewards

Quantity

Product sku :

TF1023/90KW/BK

Product description

Show Cataloge

The TF-1023/90kW is the largest model in the TF-1023 series, engineered for the heaviest industrial projects and massive pumping stations. It delivers full control under high loads with excellent operational stability, making it a powerhouse for demanding environments.

Technical Specifications

Item	Details
Model	TF-1023/90kW
Rated Power	90kW
Rated Input Current	168A
Rated Output Current	180A
AC Input Voltage	380–440V
Max DC Voltage	250–900V
IP Rating	IP20
Operating Temperature	-10°C to +50°C
Dimensions	750 × 460 × 330 mm
Warranty	3 years

Key Features

Exceptional performance for heavy-duty applications
Suitable for the largest industrial pumps
Full solar energy support
High stability under massive load conditions

Applications

Large-scale factories
Giant wells
Very large water pumping projects

Operation

Designed to run very high-capacity motors by regulating voltage and frequency to achieve optimal torque and stability.

Installation & Warranty

Input Voltage: Three-phase (3PH)
Mounting Type: Floor-standing or wall-mounted
Cover Color: Black
Warranty: 3 years
Outdoor Resistance: IP20

90kW Black Inverter

Product weight :
